A0322RTS Temperature Hardened Accelerometer
Brand: Emerson Electric Co.Premium high-accuracy accelerometer with quartz element to resist damage due to thermo shock.
Features- Range of accelerometers covers all standard applications.
- Triaxial accelerometer reduces time spent collecting data.
- Swivel-based, low-profile accelerometers eliminate cable strain.
- Many items developed in partnership with industry-leading manufacturers.
Specifications
Brand
Amplitude Linearity
- 1 % (0 Based, Least Squares, Straight Line)
Excitation Voltage, Current
- 18 to 28 Vdc / 2 to 20 mA
Frequency Range (± 3 dB)
- 0.8 to 10,000 Hz (48 to 600,000 cpm)
Measurement Range
- 50 G (&pm, 490 m/sec²)
Operating Temperature
- -54° to 121° C (-65° to 250° F)
Shock Limit
- 5,000 G Pk (49,050 m/sec²)
Transverse Sensitivity
- ≤ 5 %
Weight
- 120 g (4.2 oz.)
